MICROWAVE REACTOR

The VBCC Microwave Reactor is a high-power industrial processing system designed for advanced microwave-assisted chemical and thermal applications. Operating at 2.45 GHz with a 10 kW microwave source, the system enables rapid, volumetric, and energy-efficient heating for a wide range of materials and processes. With precise temperature control, IR-based monitoring, and integrated cooling systems, it is ideal for continuous material processing, research applications, and pilot-scale industrial development.

Applications

Microwave-Assisted Chemical Processing
Continuous Material Drying
Polymer and Composite Processing
Ceramic Component Heating
Research and Development Studies
Pilot Scale Manufacturing
Advanced Material Processing
Industrial Microwave Experiments
Catalysis and Reaction Engineering
Energy Efficient Process Development

Technical Data

Microwave Power	10 kW
Frequency	2.45 GHz
Temperature Controller	Eurotherm PID System
Temperature Monitoring	IR Pyrometer
Heating Technology	Microwave Dielectric Heating
Cooling System	Integrated Chiller + Water Cooling
Insulation	Zircar SALI High-Temperature Insulation
Operation Mode	Manual / Automatic
Atmosphere	Air / Controlled Gas (Optional)
Control System	PID / PLC Based (Optional)
Reactor Type	Customizable Quartz / Ceramic / Metal
Power Supply	415V AC, 3 Phase, 50 Hz
Safety Features	Thermal, Electrical & Microwave Interlocks

Optional Features

Touch Screen HMI Interface

SCADA Monitoring and Data Logging

Remote Monitoring Facility

Additional Temperature Sensors

Custom Reactor Length Configuration

Gas Purging Arrangement

Enhanced Safety Interlocks

PLC-Based Automation System

Advanced Process Recipe Control

Integrated Mass Flow Control System
